Name |
T-3″(75mm) pump |
T-4”(100mm) pump |
T-6”(150mm) pump |
T-8”(200mm) pump |
T-10”(250mm) pump |
U-3″(75mm) pump |
U-4”(100mm)pump |
U-6”(150mm)pump |
|
Head to |
112″(34m) |
115”(35m) |
109”(33m) |
109”(33m) |
129”(39m) |
205”(62m) |
197”(60m) |
192”(58m) |
|
Flow to |
450GPM (102M³/h) |
730GPM (165M³/h) |
1480GPM (335M³/h) |
2600GPM (600M³/h) |
3200GPM (725M³/h) |
375GPM (85M³/h) |
650GPM (147M³/h) |
1350GPM (306M³/h) |
|
solid size |
2-5inch (63.5mm) |
3inch (75mm) |
3inch（75mm) |
3inch(75mm) |
3inch(75mm) |
13/16inch (20.63mm) |
1.125inch (28.57mm) |
1.25inch (31.75mm) |
|
Pump mode |
pump axle’s dimension |
power |
engine model |
engine dimension |
rated speed |
engine rated power |
flywheel |
coupling model |
baseplate dimension |
land dimension |
|
kW |
RPM |
kW |
||||||||
|
HFCT-3 |
φ38.1*101.6 |
15 |
F2L912 |
678*704*872 |
2100 |
18 |
SAE3 |
BOWEX65 11.5″FLE-PA |
1600*900*200 |
T3-SAE3 |
|
HFCT-4 |
φ38.1*127 |
22 |
F3L912 |
730*673*815 |
2000 |
29 |
SAE3 |
BOWEX65 11.5″FLE-PA |
1900*1000*200 |
T4-SAE3 |
|
HFCT-6 |
φ38.1*127 |
30 |
F4L912 |
860*673*815 |
1550 |
32 |
SAE3 |
BOWEX65 11.5″FLE-PA |
2100*1000*200 |
T4-SAE3 |
|
HFCT-8 |
φ44.5*169.9 |
55 |
F6L912T |
1175*673*820 |
1350 |
58 |
SAE3 |
BOWEX80 11.5″FLE-PA |
2400*1100*200 |
T6-SAE3 |
|
HFCT-10 |
φ44.5*122.2 |
75 |
BF6L913 |
1134*711*910 |
1450 |
88 |
SAE3 |
BOWEX80 11.5″FLE-PA |
2600*1100*200 |
T8-SAE3 |
|
HFCU-3 |
φ38.1*103.1 |
22 |
F3L912 |
730*673*815 |
2100 |
31 |
SAE3 |
BOWEX65 11.5″FLE-PA |
1600*900*200 |
U3-SAE3 |
|
HFCU-4 |
φ38.1*126.2 |
37 |
F4L912 |
860*673*815 |
2100 |
41 |
SAE3 |
BOWEX65 11.5″FLE-PA |
1900*1000*200 |
U4-SAE3 |
|
HFCU-6 |
φ38.1*121.4 |
55 |
F6L912 |
1120*673*815 |
2000 |
65 |
SAE3 |
BOWEX65 11.5″FLE-PA |
2100*1000*200 |
U6-SAE3 |
