Product Description:
Important Features
1.Adopting the electric contral multi-point injection and theoretic air and fuel ratio conbustion strategy,the power performance and acceleration performance of nature gas are much higher than that os single point injection and lean bum engine .
2.The main maintenance parts,such as oil filter,air filter ,pressure reducing valve and ignition coil ,are all mounted in the right side ,while the inlet and outlet in the left side (Facing the fan),which bring the convenience to the maintenance.
3.The adoption of the world advanced multi-point electronic fuel injection system not only brings the lower gas consumption and better economy ,but also the higher emission shandard.
Technical Data:
| Model | 1004NG |
| Prime power(Kw)1500rpm | 32 |
| Standby power(Kw)1500rpm | 35 |
| Prime power(Kw)1800rpm | 38 |
| Standby power(Kw)1800rpm | 41 |
| Cylinder number | 4 |
| Cylinder arrangement | In line |
| Bore * stoke(mm) | 100*127 |
| Displacement(L) | 3.99 |
| Aspiration: | Naturally aspirated |
| Cycle: | 4-stroke |
| Compression ratio: | 10.3:1 |
| Total lubrication capacity(L): | 8.1 |
| Total coolant capacity:(inc. radiator) (L) | 22.8 |
| Overall dimensionsL*W*H(mm) | 1254*706*946.2 |
| Dry weight(Kg): | 486.5 |
