Product Description:
Technical Data:
| Genset Specification | Engine Specification | Genset Open Date | |||||||||
| 50HZ | 60HZ | Engine Model | Cyl | Gov | Displacement (L) | Dimention (MM) | Weight (KG) | ||||
| Genset Model | Power(kva) | Power(kva) | Fuel Cons 100% (L/H) | ||||||||
| ESP | PRP | ESP | PRP | ||||||||
| HF400P | 450 | 400 | 85 | 2206C-E13TAG3 | 6L | ECU | 12.5 | 3500*1150*2050 | 3306 | ||
| HF400P1 | 450 | 400 | 81 | 2206A-E13TAG3 | 6L | ECU | 12.5 | 3500*1150*2050 | 3150 | ||
| HF450P | 500 | 450 | 99 | 2506C-E15TAG1 | 6L | ECU | 15 | 3830*1190*2050 | 3637 | ||
| HF450P1 | 500 | 450 | 95 | 2506A-E15TAG1 | 6L | ECU | 15.2 | 3830*1190*2050 | 3600 | ||
| HF500P | 550 | 500 | 106 | 2506C-E15TAG2 | 6L | ECU | 15 | 3830*1190*2050 | 3637 | ||
| HF500P1 | 550 | 500 | 100 | 2506A-E15TAG2 | 6L | ECU | 15.2 | 3830*1190*2050 | 3600 | ||
| HF600P | 660 | 600 | 687.5 | 625 | 129 | 2806C-E18TAG1A | 6L | ECU | 18.13 | 3750*1550*2080 | 4382 |
| HF600P1 | 660 | 600 | 123 | 2806A-E18TAG1A | 6L | ECU | 18.13 | 3750*1550*2080 | 4352 | ||
| HF650P | 715 | 650 | 132 | 2806A-E18TAG2 | 6L | ECU | 18.1 | 3750*1550*2080 | 4537 | ||
| HF725P | 800 | 725 | 825 | 750 | 155 | 4006-23TAG2A | 6L | E | 22.92 | 4320*1760*2200 | 6127 |
| HF800P | 880 | 800 | 910 | 825 | 172 | 4006-23TAG3A | 6L | E | 22.921 | 4320*1760*2200 | 6130 |
| HF850P | 935 | 850 | 962.5 | 875 | 185 | 4008TAG | 8L | E | 30.561 | 4320*1760*2200 | 6130 |
| HF900P | 1000 | 900 | 195 | 4008TAG1A | 8L | E | 30.561 | 4320*1760*2200 | 6130 | ||
| HF1000P | 1100 | 1000 | 215 | 4008TAG2A | 8L | E | 30.561 | 4320*1760*2200 | 6130 | ||
| HF1000P1 | 1100 | 1000 | 215 | 4008TAG2 | 8L | E | 30.561 | 4320*1760*2200 | 6130 | ||
| HF1125P | 1250 | 1125 | 244 | 4008-30TAG3 | 8L | E | 30.561 | 4320*1760*2200 | 6130 | ||
| HF1250P | 1375 | 1250 | 1375 | 1250 | 259 | 4012-46TWG2A | 12V | E | 45.842 | 4850*2050*2500 | 8929 |
| HF1375P | 1500 | 1375 | 1500 | 1375 | 283 | 4012-46TWG3A | 12V | E | 45.842 | 4850*2050*2500 | 8987 |
| HF1375P1 | 1500 | 1375 | 281 | 4012-46TAG1A | 12V | E | 45.842 | 5000*2230*2410 | 9440 | ||
| HF1500P | 1650 | 1500 | 1650 | 1500 | 316 | 4012-46TWG4A | 12V | E | 45.842 | 5000*2230*2410 | 9482 |
| HF1500P1 | 1650 | 1500 | 1650 | 1500 | 310 | 4012-46TAG2A | 12V | E | 45.842 | 5000*2230*2410 | 9462 |
| HF1650P | 1850 | 1650 | 1875 | 1700 | 370 | 4012-46TAG3A | 12V | E | 45.842 | 5090*2230*2530 | 9889 |
| HF1705P | 1875 | 1705 | 370 | 4012-46TAG3A | 12V | E | 45.842 | 5090*2230*2530 | 10127 | ||
| HF1850P | 2030 | 1850 | 383 | 4016TAG1A | 16V | E | 61.123 | 6000*2200*2560 | 12229 | ||
| HF2050P | 2250 | 2050 | 434 | 4016TAG2A | 16V | E | 61.123 | 6000*2200*2560 | 12513 | ||
| HF2250P | 2500 | 2250 | 470 | 4016-61TRG3 | 16V | E | 61.123 | 6060*2230*2700 | 13281 | ||
