We are professional manufacturer of deutz diesel engine and deutz diesel generators.
air cooled engine deutz models: F2L912, F3L912, F4L912, F4L912T, F6L912, F6L912T, BF6L913, BF6L913C
Alternator brand : stamford , Leroy Somer, Leroy Some,Marathon .
Generator set power: 12kw 15kva, 20kw 25kva, 24kw 30kva, 36kw 45kva, 40kw 50kva, 52kw 65kva, 75kw 93.75kva, 100kw 125kva
| Model | HF14D |
| Genset |
|
| Prime power(kw/kva) when 50HZ | 12/15 |
| Prime power(kw/kva) when 60HZ | 14/17 |
| Engine |
|
| Model | F2L912 |
| Prime power | 14kW/1500rpm |
| 17kW/1800rpm | |
| Number of cylinder | 2 |
| Cylinder arrangement | vertical line |
| Cooling system | Air cooled |
| Aspiration | Naturally |
| Governor | Mechanical |
| Bore*Stroke | 100*120 |
| 50% Fuel consumption | 2.27L/hr |
| 75% Fuel consumption | 2.8L/hr |
| 100% Fuel consumption | 3.7L/hr |
| Alternator |
|
| Excitation type | Brushless excitation |
| Rated power(kw) | 14 |
| Rated current(A) | 46 |
| Insulative grade | H |
| Protection grade | IP22 |
| Voltage | 220/380V |
| Tolerance of voltage | ≤±1% |
| Dimension | 1150*900*1230mm |
| Weight | 434 |
